Description：
1. This slitting machine is suitable for slitting adhesive label paper, craft paper etc.
2. It adopts PLC with touch screen for convenient operation.
Introduction:
1. This slitting machine is suitable for slitting adhesive label paper, craft paper etc.
2. It adopts PLC with touch screen for convenient operation.
3. Unwind part uses Pneumatic brake, and PLC calculates the diameters automatically to achieve constant tension.
4. Rewind part is driven by vector motor, constant liner speed.
5. Hydraulic auto loader is used for unwind mother roll, it save human cost and time.
6. Rewind part uses hydraulic lifter to lift rewind rolls.
7.EPC system is used in this machine, the photocell and hydraulic webguide is equipped; E+L webguide for track edge/line is for optional.
8.This system has advantages of Start Buffer, Stop without loose; Meter setting; Speed Setting; Diameter calculate etc.
Main Parameter:
|
Model |
ZTM-B 1300 |
ZTM-B 1600 |
|
Maximum raw material width |
1300mm |
1600mm |
|
Maximum raw material diameter |
Ø1200mm |
Ø 1500mm |
|
Maximum winding diameter |
Ø1200mm |
Ø 1500mm |
|
The narrowest cutting width |
50mm |
50mm |
|
Mechanical speed |
250 m/min |
250m/min |
|
Paper thickness range |
40-500gsm |
40-500gsm |
|
Machine weight |
4000kgs |
5200kgs |
|
Overall dimensions |
3900×3500×1500mm |
4200×3900×1500mm |
|
Voltage |
380V |
380V |
