ZST-2000 Automatic Paper Roll Cutting and Rewinding Machine, Slitting Rewinder Machine
The machine is mainly used to slit jumbo stick paper, craft paper and other kinds of paper, width from 1600mm-2700mm.
Main technical parameter:
|
Max Jumbo roll width |
1600mm |
2000mm |
2500mm |
|
Min Jumbo roll width |
400mm |
400mm |
400mm |
|
Diameter of roll |
Ø1500mm |
Ø1500mm |
Ø1500mm |
|
Diameter of rewinding |
Ø1200mm |
Ø1200mm |
Ø1200mm |
|
Unwind dia of paper core |
3’’ and 6’’ |
3’’ and 6’’ |
3’’ and 6’’ |
|
Rewind dia of paper core |
3’’ |
3’’ |
3’’ |
|
Width of rollers |
1650mm |
2050mm |
2550mm |
|
Slitting speed |
10-350m/min(according to material) |
10-350m/min(according to material) |
10-350m/min(according to material) |
|
Tolerance of EPC |
≤0.1mm |
≤0.1mm |
≤0.1mm |
|
Range of EPC |
±75mm |
±75mm |
±75mm |
|
Min.width of produce |
50mm-1600mm |
50mm-2000mm |
50mm-2500mm |
|
Up circle knife dimension |
Ø125*70*50mm |
Ø125*70*50mm |
Ø125*70*50mm |
|
Down circle knife dimension |
Ø100*70*20mm |
Ø100*70*20mm |
Ø100*70*20mm |
|
Total power |
55KW |
60KW |
70KW |
|
Weight |
16000Kg |
17000Kg |
18000Kg |
|
overall dimension (L X W X H) |
7900mmx3100mmx2200mm |
7900mmx3500mmx2550mm |
7900mmx4000mmx2550mm |
