MAIN TECHNICAL SPECIFICATIONS ：
| Jumbo roll width | 1600-3000mm |
| Diameter of unwind | ø1600mm |
| Diameter of rewind | ø1200mm |
| Paper core size of unwind | 3''6'' |
| Paper core size of rewind | 3'' |
| Slitting speed | 8-800m/min |
| Tolerance of LPC | ≤0.1mm |
| Min.slitting width | 50mm |
| Total power | 60-100KW |
| Weight | 18000kg |
| Overall dimension | 5300mm×4520mm×2335mm |
If you have any enquiry about quotation or cooperation,please feel free to email us at zhongtai@cnslittingmachine.com or use the following enquiry form. Our sales will contact you within 24 hours. Thank you for your interest in our products.
