ZTM-F 2500mm width Jumbo roll Paper slitting rewinding machine 600M/min speed

The slitting rewinding machine is mainly used to slit Craft paper, News paper, Silicone Paper,Thermal Paper,Fluting Paper,Sublimation Paper,
Glassine paper,double side coated paper, recycled paper, paper borad etc, width range from 1600-3000mm.

Contact us

Mobile+86-13616602974

Whatsapp8613616602974

Wechat+86-13616602974

E-mailzhongtai@cnslittingmachine.com

ZTM-F1600-3000 Jumbo Paper Roll Slitter Rewinder Machine, Paper Converting Machine:

The slitting rewinding machine is mainly used to slit Craft paper, News paper, Silicone Paper,Thermal Paper,Fluting Paper,Sublimation Paper,

Glassine paper,double side coated paper, recycled paper, paper borad etc, width range from 1600-3000mm.

1. Paper thickness range: (gr/m²): 40-500 g/m2

2. Mother roll (Unwinder rolls)

Width: 1600mm-3000mm

Chucks Core: 3, 4, 6, 12inches

Max diameter: 1500 mm or max. 2100mm

Max Weight: 4000kg or more

3. Rewind roll (Output rolls)

Air shaft Core: 3, 4 or 6inches

Max diameter: 1200 mm-1500mm

4. Slitting size: Min width: 100 mm

Knfifeholders: Normal circular slitting knife or Pneumatic circular knife (can be chosen)

5. Working Speed: 600 m/min

6. Features:

Unwinder shaftless, pneumatic brake controlled (Motor controlled as optional).

Guide system electromechanical

Bowed roller (Banana roller) with hydraulic controlled

Paper Edge blowing system

Rewinder 2 drum rollers with 2 motors

Automatic ejector for finished rolls

Hydraulic unloading system for finished rolls and loading at ground level.

Main parameters:

Model

ZTM-F 1600

ZTM-F 2500

ZTM-F3000

Jumbo roll width

1600mm

2500mm

3000mm

Diameter of Unwinder roll

1200mm

1200mm

1200mm

Diameter of rewinding roll

1000mm

1000mm

1000mm

Inner dia.of paper core

3’’, 4'', 6’’ ,12''

3’’, 4'', 6’’ ,12''

3’’, 4'', 6’’ ,12''

Slitting speed

8-600m/min

8-600m/min

8-600m/min

Tolerance of EPC

≤0.1mm

≤0.1mm

≤0.1mm

Min.width of produce

50mm

50mm

50mm

Weight

15000Kg

18000Kg

22000Kg


Optional:
1, Pneumatic circular knife
2, Unwinder 2 pneumatic brakes change to 2 Motors+2 inverters + reducers and loadcell for auto tension controlled.
3, Automatic pneumatic knife moving system

4, extra air shaft 3inch, 4inch, 6inch
