The machine applies to slit jumbo film rolls of PET, OPP, CPP, PS, PVC, metalized film, laminated film, optical materials, width 2000-3000mm, etc.
The rewinder part can be 4 stations or 6 stations, min.slitting width 500mm, max. working speed 600m/min.
Technical Parameters:
|
Model |
ZTM-G2000 |
ZTM-G2500 |
ZTM-G2800 |
ZTM-G3000 |
|
Unwind max width |
2000mm |
2500mm |
2800mm |
3000mm |
|
Unwind max diameter |
Ø1200mm |
Ø1200mm |
Ø1200mm |
Ø1200mm |
|
Rewind max diameter |
Ø800mm |
Ø800mm |
Ø800mm |
Ø800mm |
|
Rewinder Roller number |
4 or 6 rollers |
4 or 6 rollers |
4 or 6 rollers |
4 or 6 rollers |
|
Paper core inner diameter |
3’’ |
3’’ |
3’’ |
3’’ |
|
Slitting speed |
10-600 m/min |
10-600 m/min |
10-600 m/min |
10-600 m/min |
|
EPC tolerance |
≤0.1mm |
≤0.1mm |
≤0.1mm |
≤0.1mm |
|
Min slitting width |
500mm |
500mm |
500mm |
500mm |
|
Totally power |
38KW |
42KW |
45KW |
50KW |
|
Weight |
15000kg |
17000kg |
18000kg |
19000kg |
|
Dimension |
3750mm×5210mm×2000mm |
4250mm×5210mm×2000mm |
4550mm×5210mm×2000mm |
4750mm×5210mm×2000mm |
 |
 |
 |
|
4 or 6 rollers Independent shaftless rewinder |
Unwind tension’s actuator is 1 set Italy RE pneumatic brake |
Use EPC uses Germany brand E+L corrective device |
 |
 |
 |
|
optional pnumatic circle knife |
PLC touch screen at frond and back |
Rewind tension’s actuator is 4 sets servo motors Through PLC to achieve a constant tension |
